www.mtsranders.dk                                                                                GAUGE BLOCKS

Select steel gauge blocks

  High quality steel gauge blocks, can be very well wringed to make a combination size. The steel
gauge blocks are available in all accuracy classes of ISO 3650 (2, 1, 0, K). Only the most commonly
used sizes can be found in this catalog. Special sizes and sets are available on request, as well as
special sets for calibration of micrometers and calipers.

	 Hardness: approx. 800 HV.                                	 Sets delivered in luxurious wooden case.
	 Expansion coefficient: α = 11.5 · 10‑6 K‑1.              	 Sets optionally available in an ABS case for
	 Cross-section: 0.5 - 10 mm: 30 x 9 mm,  
                                                              ESD cleanroom (Material: ABS Acrylonitrile
  	      > 10 mm: 	35 x 9 mm.                                 Butadiene Styrene).
	 ISO 3650.                                                	 Plastic cases for separate gauge blocks are
	 Delivery with a traceable manufacturer                     optionally available. For these cases see
                                                              plastic cases for gauge blocks elsewhere in
  measuring report.                                           the catalog.
	 Delivery on request with a DAkkS certificate,

  UKAS acknowledged.

                                                            Steel gauge blocks in sets

                                                             Item         Class  Price  Size   Increment  Pie- 
                                                            No.                  DKK    mm mm ces

                                                             M32: 	       1               1.005        	 – 	1
                                                            831.915 	     0               1.01 - 1.09  	   0.01 	 9
                                                            831.914 	                     1.1 - 1.9    	 0.1 	 9
                                                                                          1 - 9        	 1   	 	 9
                                                                       	                10 - 30        	 10     	 	 3
                                                                       	                50             	 – 	1


                                                             M47: 	       1               1.005        	–          	1
                                                            831.911 	     0               1.00 - 1.09  	   0.01    	 10
                                                            831.910 	                     1.1 - 1.9    	 0.1       	9
                                                                                          2 - 25       	 1   	     	 24
                                                                       	                50 - 100       	 25     	  	3


                                                             M87: 	                       0.5 	 – 	 1
                                                            831.909
                                                            831.908 	     1               1.001 - 1.009 	     0.001 	 9
                                                                          0
Steel gauge blocks, per piece                                          	                  1.00 - 1.50 	   0.01 	 51

Size               Increment  ISO 3650/1 ISO 3650/0                                       2.0 - 10.0 	 0.5 	 17
mm                    mm Price DKK Price DKK
                                                                                        20 - 100       	 10     	 	 9

    0.5                –                                     M103: 	      1               0.5          	–          	1
  1                    –                                    831.907 	     0               1.005        	–          	1
    1.0005             –                                    831.906 	                     1.00 - 1.50  	   0.01    	 51
    1.001 - 1.009      0.001                                                              2.0 - 25.0   	 0.5       	 47
    1.01 - 1.5        0.01                                             	                50 - 100       	 25     	  	3
    1.6 - 1.9         0.1
    2.0 - 5.5         0.5
    6.0 - 10.0        0.5                                    M112: 	                      0.5 	 – 	 1
  10.5 - 15.0         0.5                                   831.905
  15.5 - 20.0         0.5                                   831.904 	     1               1.0005       	 – 	1
  20.5 - 25.0         0.5                                                 0
  30                   –                                               	                  1.001 - 1.009 	     0.001 	 9
  40                   –
  50                   –                                               	                  1.00 - 1.50 	   0.01 	 51
  60                   –
  70                   –                                                                  2.0 - 25.0 	 0.5 	 47
  75                   –
  80                   –                                                                50 - 100       	 25     	 	 3
  90                   –
100                    –                                     M122: 	                      0.5 	 – 	 1
                                                            831.903
                                                            831.902 	     1               1.0005       	 – 	1
                                                                          0
                                                                       	                  1.001 - 1.009 	     0.001 	 9

                                                                       	                  1.00 - 1.50 	   0.01 	 51

                                                                       	                  1.6 - 1.9 	 0.1 	 4

                                                                                          2.0 - 25.0 	 0.5 	 47

                                                                                        30 - 70        	 10     	 	 5    C11.210.MTS.20250410

                                                                                        75 	 – 	 1

                                                                                        80 - 100       	 10     	 	 3
