www.mtsranders.dk                                                                                GAUGE BLOCKS

Select ceramic gauge blocks

  High quality ceramic gauge blocks, can be very well wringed to make a combination size. The
ceramic gauge blocks are available in all accuracy classes of ISO 3650 (2, 1, 0, K). Only the most
commonly used sizes can be found in this catalog. Special sizes and sets are available on request, as
well as special sets for calibration of micrometers and calipers.

	 Hardness: approx. 1350 HV.                               	 Delivery with a traceable manufacturer
	 Expansion coefficient: α = 9.3 · 10‑6 K‑1.                 measuring report.
	 Cross-section: 0.5 - 10 mm: 30 x 9 mm,  
                                                            	 Delivery on request with a DAkkS certificate,
  	      > 10 mm: 	35 x 9 mm.                                 UKAS acknowledged.
	 ISO 3650.
                                                            	 Sets delivered in luxurious wooden case.
                                                            	 Plastic cases for separate gauge blocks are

                                                              optionally available. For these cases see
                                                              plastic cases for gauge blocks elsewhere in
                                                              the catalog.

                                                            Ceramic gauge blocks in sets

                                                             Item         Class  Price  Size   Increment  Pie- 
                                                            No.                  DKK    mm mm ces

                                                             M32: 	       1               1.005        	 – 	1
                                                            831.085 	     0               1.01 - 1.09  	   0.01 	 9
                                                            831.084 	                     1.1 - 1.9    	 0.1 	 9
                                                                                          1 - 9        	 1   	 	 9
                                                                       	                10 - 30        	 10     	 	 3
                                                                       	                50             	 – 	1


                                                             M47: 	       1               1.005        	–          	1
                                                            831.081 	     0               1.00 - 1.09  	   0.01    	 10
                                                            831.080 	                     1.1 - 1.9    	 0.1       	9
                                                                                          2 - 25       	 1   	     	 24
                                                                       	                50 - 100       	 25     	  	3


                                                             M87: 	                       0.5 	 – 	 1
                                                            831.079
                                                            831.078 	     1               1.001 - 1.009 	     0.001 	 9
                                                                          0
Ceramic gauge blocks, per piece                                        	                  1.00 - 1.50 	   0.01 	 51

Size               Increment  ISO 3650/1 ISO 3650/0                                       2.0 - 10.0 	 0.5 	 17
mm                    mm Price DKK Price DKK
                                                                                        20 - 100       	 10     	 	 9

    0.5                –                                     M103: 	      1               0.5          	–          	1
  1                    –                                    831.077 	     0               1.005        	–          	1
    1.0005             –                                    831.076 	                     1.00 - 1.50  	   0.01    	 51
    1.001 - 1.009      0.001                                                              2.0 - 25.0   	 0.5       	 47
    1.01 - 1.50       0.01                                             	                50 - 100       	 25     	  	3
    1.6 - 1.9         0.1
    2.0 - 5.5         0.5
    6.0 - 10.0        0.5                                    M112: 	                      0.5 	 – 	 1
  10.5 - 15.0         0.5                                   831.075
  15.5 - 20.0         0.5                                   831.074 	     1               1.0005       	 – 	1
  20.5 - 25.0         0.5                                                 0
  30                   –                                               	                  1.001 - 1.009 	     0.001 	 9
  40                   –
  50                   –                                               	                  1.00 - 1.50 	   0.01 	 51
  60                   –
  70                   –                                                                  2.0 - 25.0 	 0.5 	 47
  75                   –
  80                   –                                                                50 - 100       	 25     	 	 3
  90                   –
100                    –                                     M122: 	                      0.5 	 – 	 1
                                                            831.073
                                                            831.072 	     1               1.0005       	 – 	1
                                                                          0
                                                                       	                  1.001 - 1.009 	     0.001 	 9

                                                                       	                  1.00 - 1.50 	   0.01 	 51

                                                                       	                  1.6 - 1.9 	 0.1 	 4

                                                                                          2.0 - 25.0 	 0.5 	 47

                                                                                        30 - 70        	 10     	 	 5    C11.314.MTS.20250410

                                                                                        75 	 – 	 1

                                                                                        80 - 100       	 10     	 	 3

More information: www.schut.com/PDFs/2025-p367-EN.pdf
