Page 317 - Schut Catalog

www.promet.se SCALE UNITS

Digital horizontal scale units

These scale units are available in two different models. Up to 300 mm the model matches the photo
of the 906.403, from 450 mm the photo of the 906.406.

 Measuring range: 0 - 1000 mm. Item No. Measuring Accuracy Price
 Resolution: 0.01 mm. range/mm mm SEK
 Repeatability: 0.01 mm.
 mm/inch conversion. 906.400 0 - 100 ± 0.03 428.40
 ABS/INC switchable (from 450 mm). 906.401 0 - 150 ± 0.03 428.40
 On/off switch. 906.402 0 - 200 ± 0.03 624.00
 Reset. 906.403 0 - 300 ± 0.04 996.00
 Preset (from 450 mm).
 Max. measuring speed: 906.404 0 - 450 ± 0.05 1,692.00
906.405 0 - 500 ± 0.05 2,004.00
< 500 mm: 1.5 m/s, 906.406 0 - 600 ± 0.05 2,772.00
≥ 500 mm: 1 m/s. 906.408 0 - 800 ± 0.06 4,224.00
 Power supply: 906.409 0 - 1000 ± 0.07 5,280.00
906.400 - 403: 1 battery type V357,
906.404 - 409: 1 battery type CR2032. Options:
836.535 Spare battery type V357 10.80
495.157 Spare battery type CR2032 6.00

906.403

906.406

Digital vertical scale units  Reset. C16.218.Promet.20240517
 Preset (from 500 mm).
 Measuring range: 0 - 1000 mm.  Max. measuring speed: 1 m/s.
 Resolution: 0.01 mm.  Power supply:
 Repeatability: 0.01 mm.
 mm/inch conversion. 1 battery type V357
 ABS/INC switchable. (except 906.416 - 419).
 On/off switch.
906.417
Item No. Measuring Accuracy Price
range/mm mm SEK

906.415 0 - 100 ± 0.03 768.00
906.416 0 - 150 ± 0.03 768.00
906.417 0 - 200 ± 0.03 984.00
906.418 0 - 300 ± 0.04 1,368.00
906.419 0 - 450 ± 0.05 1,824.00
906.420 0 - 500 ± 0.05 2,316.00
906.421 0 - 600 ± 0.05 3,012.00
906.423 0 - 800 ± 0.06 3,948.00
906.424 0 - 1000 ± 0.07 5,448.00
Options:
836.535 Spare battery type V357 10.80
495.157 Spare battery type CR2032 6.00

© 2024, Schut Geometrische Meettechniek bv 317 Promet Precision 2023/2024-D
