P. 314

GRADUATED RULERS                                                                       www.promet.se

Stainless steel rulers

	 Measuring range: 0 - 2000 mm.                  Item No.       Dimensions 	             Price SEK
	 Graduation: 1 mm.                                             l x w x t/mm                 160.80
	 Matt chrome-plated stainless steel surface.                                                888.00
	 With mm graduation on the upper edge.
	 With 0.5 mm graduation on the lower 	                                                    1,188.00

  edge.

                                                  With mm/0.5 mm graduation:
                                                  775.584 	      1000	x	35	x	1.2
                                                  775.585 	      1500	x	40	x	2
                                                  775.586 1 	    2000	x	40	x	2

                                                  With mm/mm graduation:
                                                  The first 100 mm on the lower edge have a 0.5 mm
                                                  graduation.
                                                  775.304 1 	    2000	x	41	x	2            2,376.00

                                                1	Delivery ex Groningen, Netherlands.

  Stainless steel rulers                                                                  910.323

	 Measuring range: 0 - 1000 mm.
	 Graduation: 1 mm on the front side on the

  upper and lower edges, 0.5 mm on the back
  side on the upper and lower edges.
	 Matt chrome-plated stainless steel surface.
	 EC class II.
	 Etched graduation.

                                                       Item No.           Dimensions 	      Price
                                                       910.323            l x w x t/mm      SEK
                                                       910.324              300 x 30 x 1   52.80
                                                       910.325              500 x 30 x 1   64.80
                                                                          1000 x 30 x 1   141.60

Self-adhesive rulers

	 Measuring range: 0 - 400 mm.                        Vernier 0.1 mm
	 Graduation: 1 mm, vernier: 0.1 mm.                  	 10 scale devisions on 19 mm.
	 Blue anodized aluminum.                             	 Non-adhesive, furnished with two fixing
	 With self-adhesive back.
	 Suitable for positioning on measuring devices         holes ø 2.5 mm.

  and machine elements.

                                                  Item No. Measuring 	 Dimensions 	 Price
                                                                 range/mm l x w x t/mm SEK

                                                  775.901 	      0	-	200  	 208	x	16	x	0.5 69.60              C14.203.Promet.20240517
                                                  775.902 	      0	-	300  	 308	x	16	x	0.5 121.20
                                                  775.903 	      0	-	400  	 408	x	16	x	0.5 168.00

                                                  775.900 Vernier 0.1 mm 	 40	x	10	x	0.5 28.80

© 2024, Schut Geometrische Meettechniek bv        314                           Promet Precision 2023/2024-D
