www.promet.se GRADUATED RULERS

Stainless steel rulers with L → R or R → L numbering

 Measuring range: 0 - 12 000 mm. Available on request:
 Graduation: 1 mm (type B: 0.5 mm). – with graduation from top to bottom or from
 Matt chrome-plated stainless steel surface.
 Etched graduation. bottom to top,
 EC class II (up to 4000 mm). – with different combinations (mm/mm,
 Rulers from the main table with hanger hole.
mm/inch, mm/blanc, etc.),
– with 0-point in the middle.
– Thickness: from 300 mm: 1 mm,

from 500 mm: 2 mm.

835.124

835.266

Item No. Price Item No. Price Item No. Price Item No. Price Dimensions
SEK SEK SEK SEK l x w x t/mm

L → R type A: R → L type A: L → R type B: R → L type B: 835.355
835.120 18.00 835.121 18.00 835.421 18.00 835.422 18.00 150 x 13 x 0.5
835.122 21.60 835.123 21.60 835.298 21.60 835.440 21.60 200 x 13 x 0.5
835.124 25.20 835.125 25.20 835.427 25.20 835.441 25.20 250 x 13 x 0.5
835.126 27.60 835.127 27.60 835.129 27.60 835.442 27.60 300 x 13 x 0.5
835.130 46.80 835.131 46.80 835.354 46.80 835.443 46.80 500 x 18 x 0.5
835.132 120.00 835.133 120.00 835.252 120.00 835.444 120.00 1000 x 18 x 0.5
835.134 180.00 835.135 180.00 835.428 180.00 835.445 180.00 1500 x 18 x 0.5
835.136 289.20 835.137 289.20 835.429 289.20 835.446 289.20 2000 x 18 x 0.5
835.138 387.60 835.139 387.60 835.430 387.60 835.447 387.60 2500 x 18 x 0.5
835.140 439.20 835.141 439.20 835.431 439.20 835.448 439.20 3000 x 18 x 0.5
835.142 480.00 835.143 480.00 835.432 480.00 835.449 480.00 3500 x 18 x 0.5
835.144 924.00 835.145 924.00 835.433 924.00 835.450 924.00 4000 x 18 x 0.5
835.146 1,068.00 835.147 1,068.00 835.413 1,068.00 835.451 1,068.00 5000 x 18 x 0.5
835.148 1,404.00 835.149 1,404.00 835.434 1,404.00 835.452 1,404.00 6000 x 18 x 0.5
835.150 2,340.00 835.151 2,340.00 835.035 2,340.00 835.453 2,340.00 7000 x 30 x 1
835.152 2,700.00 835.153 2,700.00 835.435 2,700.00 835.454 2,700.00 8000 x 30 x 1
835.154 2,964.00 835.155 2,964.00 835.436 2,964.00 835.455 2,964.00 9000 x 30 x 1
835.156 3,708.00 835.157 3,708.00 835.437 3,708.00 835.456 3,708.00 10000 x 30 x 1
835.158 4,008.00 835.159 4,008.00 835.438 4,008.00 835.457 4,008.00 11000 x 30 x 1
835.160 4,476.00 835.161 4,476.00 835.439 4,476.00 835.458 4,476.00 12000 x 30 x 1

Type A: mm / mm (bottom and top side 1 mm graduation).
Type B: 0.5 mm / 1 mm (top side 0.5 mm, bottom side 1 mm graduation).

Rulers with a self-adhesive back

Item No. Additional costs Price SEK With 0-point in the middle

835.165 For rulers 165.60 Item No. Dimensions Price
up to 1000 mm (price per piece) l x w x t/mm SEK
For rulers 165.60 54.00
from 1000 mm (price per meter) 835.266 200 x 13 x 0.5 C14.305.Promet.20240517

The self-adhesive back is not separately available. Other sizes are also available.
