P. 168
DIAL INDICATOR STANDS www.promet.se
Measuring stands
Universal measuring stands with a granite measuring table.
Clamping shaft: ø 8 mm (optional available DIN 876/0.
clamp with clamping shaft ø 28 mm). Dimensions transverse arm:
Fine adjustment: 5 mm (999.680). ø 20 x 150 mm (999.681),
Total height: 240 mm (999.680/681), ø 20 x 210 mm (999.682/683/684/685).
Column:
355 mm (999.682/683), ø 30 x 200 mm (999.680/681),
370 mm (999.684/685). ø 30 x 300 mm (999.682/684),
Max. measuring height: 260 mm ø 30 x 300 mm (999.683/685: helical threaded
(999.682/683/684/685). with anti drop facility).
Effective arm length: Measuring table delivered with a
max. 165 mm (999.682/683/684/685), manufacturer measuring report (only
(999.681: max. 105 mm, 999.680: 68 mm). 999.684/685).
Measuring table: granite.
999.680
999.681 999.682/684
Item No. Measuring Dimensions Price 999.683/685
height/mm table l x w x h/mm SEK Promet Precision 2023/2024-D
999.680 140 150 x 100 x 40 3,108.00 C06.311.Promet.20240517
999.681 160 150 x 100 x 40 2,784.00
999.682 260 250 x 200 x 55 3,804.00
999.683 260 250 x 200 x 55 4,044.00
999.684 260 400 x 400 x 70 4,584.00
999.685 260 400 x 400 x 70 4,824.00
Option: 2,136.00
999.679 Clamp ø 28 mm
© 2024, Schut Geometrische Meettechniek bv 168
