www.promet.se DIAL INDICATOR STANDS
Measuring stands
Universal measuring stands with a cast iron, ground measuring table.
Clamping shaft: ø 8 mm (optional available Measuring table: ground,
clamp with clamping shaft ø 28 mm). 906.506/507/508: flat anvil/base,
906.516/517: round flat anvil
Fine adjustment: 5 mm (height anvil: 13.5 mm),
(906.506/508/516/518). 906.518/519: round serrated anvil
(height anvil: 13.5 mm).
Total height: 250 mm (906.508: 350 mm).
Max. measuring height: 160 mm Flatness table: ≤ 10 µm.
Dimensions transverse arm: ø 20 x 150 mm
(906.508: 260 mm).
Effective arm length: 68 mm (906.507: max. (906.507/517/519).
Column: ø 30 x 200 mm (906.508: helical
105 mm, 906.517/519: max. 95 mm).
threaded 300 mm with anti drop facility).
906.506
906.508 906.517
906.518
906.507 906.516
Item No. Measuring Dimensions Price 906.519
height/mm table l x w x h/mm SEK
999.679
906.506 140 140 x 105 x 50 1,968.00 Promet Precision 2023/2024-D
906.507 160 140 x 105 x 50 1,644.00
906.508 260 140 x 105 x 50 2,184.00
906.516 130 ø 60 x 65 1,968.00
906.517 145 ø 60 x 65 1,644.00
906.518 130 ø 60 x 65 2,184.00
906.519 145 ø 60 x 65 1,644.00
C06.310.Promet.20240517
Option: 2,136.00
999.679 Clamp ø 28 mm
© 2024, Schut Geometrische Meettechniek bv 167
