Extensions for inserts
Steel extensions for inserts with thread M2.5.
Item No. Length mm Price SEK M2.5-6g Item No. Length mm Price SEK
61.20 5 63.60
Extensions with A = ø 4 mm: 61.20 Extensions with A = ø 5 mm: 63.60
852.446 10 61.20 852.465 10 63.60
852.447 15 61.20 852.466 15 63.60
852.448 20 61.20 852.467 20 63.60
852.449 25 61.20 852.468 25 63.60
852.450 30 61.20 852.469 30 63.60
852.451 35 61.20 852.470 35 63.60
852.452 40 61.20 852.471 40 63.60
852.453 45 61.20 852.472 45 63.60
852.454 50 61.20 852.473 50 63.60
852.455 55 61.20 L 852.474 55 63.60
61.20 63.60
852.456 60 61.20 852.475 60 63.60
852.457 65 61.20 852.476 65 63.60
852.458 70 61.20 852.477 70 63.60
852.459 75 61.20 852.478 75 63.60
852.460 80 61.20 852.479 80 63.60
852.461 85 61.20 M2.5- 6H 852.480 85 63.60
852.462 90 852.481 90
852.463 95 852.482 95
852.464 100 A 852.483 100
Adapters for inserts
Adapter for attaching other inserts to dial indicators and probes with an interchangeable insert with
thread M2.5.
Item No. External/internal thread Price SEK ø4
M2
960.276 M2.5/M2 160.80 M2.55
Käfer long angular heads for dial indicators
Clamping shaft: ø 8 mm.
Extensions stem: ø 8 mm.
Thread for inserts and extensions: M2.5.
Max. probe travel: 4 mm.
One extension and extra insert are needed for
the angular head to function.
Please see the dial indicator accessories
section for these inserts.
851.019 851.020 851.021 851.024 Item No. Description Price SEK C05.336.Promet.20240517
Long angular heads: 3,204.00
851.019 Long angular head 90° 3,204.00
851.020 Long angular head 45° 2,304.00
851.021 Long angular head 0°
2,424.00
Extensions: 2,424.00
851.022 Extension 15 mm 2,424.00
851.023 Extension 25 mm 2,424.00
851.024 Extension 50 mm 3,264.00
851.025 Extension 75 mm
851.026 Extension 100 mm
