DIAL INDICATORS www.promet.se

Peacock dial indicators 0.005 and 0.001 mm

 Measuring range: 0 - 5 mm.
 Graduation: 0.005 or 0.001 mm.
 Clamping stem: ø 8 mm.
 Rotatable dial.
 Flat back or back with lug *.
 DIN 878.

855.555 855.525 855.535 855.509

Item No. Measuring Dial Max. hysteresis Measuring Accuracy Price
range/mm ø/mm mm force/N mm SEK
47
Graduation 0.005 mm: 53 0.004 < 1.4 ± 0.012 1,476.00
855.535 * 0 - 3 66.5
Graduation 0.001 mm: 66.5 0.003 < 1.5 ± 0.006 924.00
855.509 0 - 1 0.003 < 1.5 ± 0.007 1,872.00
855.525 * 0 - 2 0.003 < 1.5 ± 0.010 2,460.00
855.555 * 0 - 5
* Back with lug.

Peacock dial indicators with back plunger

The back plunger dial indicator is characterized with easy handling since the spindle with the
contact point is moving in the direction perpendicular to the dial face and the gauge is more compact.
The dial indicator of this type is convenient for use in achieving a parallelism in machine guides and
for applications where most other dial indicators are not applicable, give too great of a measurement
error, or are difficult to read due to the applied arrangement.

 Measuring range: 0 - 5 mm. 38 38
 Graduation: 0.01 mm.
 Accuracy: ± 0.018 mm. ø6.35 ø6
 Repeatability: 0.003 mm.
 Max. hysteresis: ± 0.004 mm. 44 44 28.1
 Measuring force: < 1.4 N. 9 9
 Rotatable dial.
 Scale numbering: 0 - 100. 28.1
 DIN 878. 3.5 3.5 855.560
57
855.558 4.5 547.5

38

Item No. Measuring Clamping Price
range/mm stem ø/mm SEK

58.5 ø8.0 0 855.558 0 - 5 6.35 1,044.00
12.5 5.5 16.5 0.03

3.5 855.560 0 - 5 6 1,224.00 C05.219.Promet.20240517

4.5 855.559 Clamping stem on back side: 1,044.00
855.559 0 - 5 8
