www.promet.se DIAL INDICATORS

Absolute horizontal digital dial indicators

 Measuring range: 0 - 30 mm.  Reversible measuring direction.
 Resolution: 0.001 mm.  Protection: IP54.
 mm/inch conversion.  Delivery with a manufacturer measuring report.
 Digimatic data output.  Power supply:
 On/off switch.
 Reset/preset. 910.085: 1 battery type CR1632,
 Ceramic stylus tip. 910.086: 1 battery type CR2032.
 With dovetail joint (incl. lug) and clamping USB interface and wireless USB receiver and

stem ø 8 mm. transmitter available on request.
 Measuring force: ≤ 2 N.

910.085

Item No. Measuring Resolution Accuracy Price
range/mm mm mm SEK

910.085 0 - 12.7 0.001 ± 0.005 1,116.00
910.086 0 - 30 0.001 ± 0.006 1,368.00

Options: 21.60
497.955 Spare battery type CR1632 6.00
495.157 Spare battery type CR2032

Digital dial indicator with calculation function

Robust digital dial indicator with built-in calculation function for easy determination of diameters
by means of measuring a curved surface. Suitable for measuring both inside and outside diameters
and multifunctional dial indicator applications. Delivery with measuring bases of 10, 20, 30, 60 and
100 mm.

 Measuring range: 0 - 13 mm.  Hold function.
 Resolution: 0.005 mm.  Clamping stem: ø 8 mm.
 mm/inch conversion.  Aluminum construction.
 On/off switch.  Delivery in a plastic case.
 Reset.  Power supply: 1 battery type CR2032.

Item No. Measuring Accuracy Price C05.329.Promet.20240517
range/mm mm SEK

907.884 0 - 13 ± 0.005 * 3,648.00
Option:
495.157 Spare battery type CR2032 6.00
* Accuracy of the indicator without the use of
measuring bases. The accuracy with measuring bases
depends on the radius and form deviation of the
workpiece.

© 2024, Schut Geometrische Meettechniek bv 133 Promet Precision 2023/2024-D
