P. 130
DIAL INDICATORS www.promet.se
Absolute digital dial indicators
Measuring range: 0 - 50.8 mm. Adjustable tolerance limits (except 910.004).
Resolution: 0.01 mm or 0.001 mm. Flat back.
mm/inch conversion. With additional back with lug
ABS/INC switchable.
LCD display 330° rotatable. (only 909.998, 910.001/004).
Digimatic data output. Protection: IP54.
On/off switch. Delivery with a manufacturer measuring report.
Reset/preset. Power supply: 1 battery type CR2032.
Ceramic stylus tip.
Max. measuring speed: unlimited.
Measuring force: ≤ 2 N.
Clamping stem: ø 8 mm.
Dial diameter: 60 mm.
Reversible measuring direction.
With determination of the reversal point (only
910.004).
USB interface: 909.998 910.004
– For data transfer to PC
Item No. Measuring Resolution Accuracy Price
(e.g. Excel, Word). range/mm mm mm SEK
– Operating system:
Windows and other.
– PC connection: USB.
– No software or driver to install.
– Foot switch (optional).
909.998 0 - 12.7 0.001 ± 0.004 1,788.00
909.999 0 - 25.4 0.001 ± 0.005 2,352.00
910.000 0 - 50.8 0.001 ± 0.006 3,252.00
910.001 0 - 12.7 0.01 ± 0.01 1,008.00
910.002 0 - 25.4 0.01 ± 0.01 1,284.00
910.003 0 - 50.8 0.01 ± 0.015 1,788.00
± 0.004 1,956.00
909.686 For internal measurements:
910.004 0 - 12.7 0.001
909.611 With Bluetooth: 0.001 ± 0.004 1,920.00
910.079 0 - 12.7 0.01 ± 0.01 1,200.00
910.082 0 - 12.7
909.687 Options: 6.00
910.039/038 495.157 Spare battery type CR2032 1,308.00
909.613 909.686 1,2 USB interface
909.687 Footswitch for USB interface 222.00
910.038 Wireless USB receiver 600.00
910.039 2 Wireless transmitter 600.00
909.611 Retraction lever 13.20
909.613 Cable retraction device (0.4 m) 174.00
76.80
(maximum travel 10 mm)
909.614 Retraction lever C05.326.Promet.20240517
(maximum travel 12.7 mm)
909.614 1 Standard configured for PC with English (US) keyboard.
Also available on request for alternative keyboards.
2 For instruments with a Digimatic data output.
© 2024, Schut Geometrische Meettechniek bv 130 Promet Precision 2023/2024-D
