Peacock dial indicator tester
For checking the accuracy of dial indicators,
lever-type dial test indicators and gauges.
Measuring range: 20 mm
(max. spindle thread pitch: 25 mm).
Graduation: 0.001 mm.
Accuracy: ± 0.002 mm.
Several mounting possibilities:
vertical intake ø 8 mm,
horizontal intake ø 6 mm.
Please see the dial test indicator
accessories section for other
mounting possibilities.
Provided with mirror for dials facing
upward.
Type NB.
Delivery in an aluminum carrying
case with a manufacturer measuring
report.
Item No. Description Price SEK
855.620 Dial indicator tester 15,408.00
Dial indicator backs
Dial indicators are by default delivered with either a flat back or a back with lug. For many dial
indicators alternative back plates are available, which considerably increases the flexibility for mount
ing the dial indicators.
The many possible combinations make it impossible to specify them all. The given
selection is an impression of the possibilities.
With lug in the middle With threaded bush
With shifted lug With adjustable fixture With magnet
With fixing shank Flat back C05.305.Promet.20240517
