P. 110
INT. & EXT. MICROMETERS / INTERNAL MEASURING INSTRUMENTS www.promet.se
Groove micrometers
Micrometers for measuring e.g. steps in bores and internal cross grooves. With double graduation
for internal and external measurements. By means of the disk-shaped measuring faces the wide, depth
and location of grooves in bores can be determined.
Measuring range: Diameter measuring faces:
external measuring: 0 - 100 mm, 907.137: 6.5 mm,
internal measuring: 1.6 - 101.5 mm. 907.138 - 907.141: 13 mm.
Double graduation.
Graduation: 0.01 mm.
Accuracy: ± 0.01 mm.
ø6.5 ø3 ø6.5 ø5 907.137
0.75 0.75
907.137 Item No. Ext. measuring Int. measuring Price
range/mm range/mm SEK
ø13 ø6.35 ø13 ø10 ø16 907.137 0 - 25 1.6 - 26.5 3,528.00
907.138 0 - 25 1.6 - 26.5 3,528.00
0.75 0.75 907.139 25 - 50 26.5 - 51.5 4,092.00
907.140 50 - 75 51.5 - 76.5 4,728.00
907.138 - 141 907.141 75 - 100 76.5 - 101.5 5,436.00
Two-point internal measuring instruments
Measuring range: 20 - 150 mm.
Graduation: 0.01 mm.
Interchangeable measuring inserts.
Delivery in a plastic case with measuring
inserts.
855.502
C MIN
Item No. Measuring Amax Cmin Dmax Price D C04.281.Promet.20240517
range/mm mm mm mm SEK MAX
855.501 20 - 34 60 2 3 3,192.00 A MAX
855.502 30 - 60 75 2.5 5 3,192.00
855.503 55 - 150 90 4 9 3,612.00
© 2024, Schut Geometrische Meettechniek bv 110 Promet Precision 2023/2024-D
