P. 108
STICK MICROMETERS www.promet.se
Inside micrometers with interchangeable anvils
Screw thread micrometers for internal measurements of pitch diameters. The interchangeable anvils
allow measurements of several kinds of screw thread.
Measuring range: 75 - 300 mm. Insert shaft: ø 5 mm.
Graduation: 0.01 mm. Delivery incl. setting gauge for metric thread,
Locking screw (125 - 300 mm).
60° flank angle.
Item No. Measuring Accuracy Price Item No. Threads per inch Price SEK
range/mm mm SEK
Inserts for Whitworth threads,
Inside micrometers without inserts: 55° flank angle, per pair:
906.924 75 - 100 ± 0.035 1,044.00 906.940 60 - 48 267.60
906.925 100 - 125 ± 0.035 1,176.00 906.941 48 - 40 267.60
906.926 125 - 150 ± 0.035 1,296.00 906.942 40 - 32 267.60
906.927 150 - 175 ± 0.035 1,416.00 906.944 32 - 24 267.60
906.928 175 - 200 ± 0.045 1,548.00 906.945 24 - 18 267.60
906.929 200 - 225 ± 0.045 1,668.00 906.946 18 - 14 267.60
906.930 225 - 250 ± 0.045 1,788.00 906.947 14 - 10 267.60
906.931 250 - 275 ± 0.045 1,920.00 906.948 10 - 7 267.60
906.932 275 - 300 ± 0.055 2,040.00 906.949 7 - 4.5 267.60
906.950 4.5 - 3.5 267.60
906.951 Set 60 - 3.5 2,232.00
Item No. Pitch/mm Price SEK Item No. Threads per inch Price SEK
Inserts for metric threads, 267.60 Inserts for UN, UNC and UNF threads,
60° flank angle, per pair: 267.60 60° flank angle, per pair:
906.933 0.4 - 0.5 267.60 906.952 64 - 48 267.60
906.934 0.6 - 0.9 267.60 906.953 44 - 28 267.60
906.935 1 - 1.75 267.60 906.954 24 - 14 267.60
906.936 2 - 3 267.60 906.955 13 - 9 267.60
906.937 3.5 - 5 1,332.00 906.956 8 - 5 267.60
906.938 5.5 - 7 906.957 4.5 - 3.5 267.60 C04.282.Promet.20240517
906.939 Set 0.4 - 7 906.958 Set 64 - 3.5 1,332.00
© 2024, Schut Geometrische Meettechniek bv 108 Promet Precision 2023/2024-D
