www.prenar.ee                                                   DIAL INDICATORS

Absolute digital dial indicators

  Absolute digital dial indicators with a function to set tolerance limits with clear optical Go (NoGo)
reading.

	 Measuring range: 0 - 50 mm.                     	 Max. measuring speed: unlimited.
	 Resolution: 0.01 mm or 0.001 mm.                	 Clamping stem: ø 8 mm.
	 mm/inch conversion.                             	 Dial diameter: 60 mm.
	 ABS/INC switchable.                             	 Reversible measuring direction.
	 With data output.                               	 Flat back and additional back with lug.
	 Adjustable tolerance limits.                    	 Protection: IP54.
	 Tolerance display by means of illuminated       	 Delivery with a manufacturer measuring report.
                                                   	 Power supply: 1 battery type CR2032.
  green LED at GO value.
	 On/off switch.
	 Reset/preset.
	 Ceramic stylus tip.

                                                            USB interface:
                                                             – For data transfer to PC

                                                               (e.g. Excel, Word).
                                                             – Operating system:

                                                               Windows and other.
                                                             – PC connection: USB.
                                                             – No software or driver to install.
                                                             – Foot switch (optional).

                                                   906.618

                                Item No. Measuring 	 Resolution 	 Accuracy 	               Price
                                              range/mm      mm             mm              EUR
                       906.870

                                910.221 	 0	-	12.7 	 0.001      	 ± 0.004
                                910.222 	 0	-	25.4 	 0.001      	 ± 0.004
                                910.223 	 0	-	50.8 	 0.001      	 ± 0.005

                                906.870 	 0	-	12.7 	 0.01       	 ± 0.01
                                906.871 	 0	-	25.4 	 0.01       	 ± 0.01
                                906.872 	 0	-	50.8 	 0.01       	 ± 0.015

          909.687      909.611  Options:
      906.619/910.038           495.157 Spare battery type CR2032
909.613                         906.618 1,2 USB interface                                                C05.330.Prenar.20240422
                                909.687 Footswitch for USB interface
                                910.038 Wireless USB receiver
                                906.619 2 Wireless transmitter
                                909.611 Retraction lever
                                909.613 Cable retraction device (0.4 m)

                                            (maximum travel 10 mm)
                                909.614 Retraction lever

                                            (maximum travel 12.7 mm)

                       909.614 1	Standard configured for PC with English (US) keyboard.
                                    Also available on request for alternative keyboards.
                                  2	With micro-USB connection.
