Thread measuring wires

For measuring external threads using the three-wire method. The flank diameter can be determined
according to the measured diameter, using tables.
 For micrometers with measuring faces ø 6.35,

ø 6.5 or ø 8 mm. (Also available for measuring
faces ø 6.8 and ø 7.5 mm.)
 Very high measuring accuracy: ± 0.001 mm.
 In pairs or in a set.
 The wire holders are held in position on the
anvil and spindle by a spring clamp.
 The wires are mounted on the holder in
such a way that they position themselves
on the thread.

d2 dD
M
C03.244.MTS.20250410
Thread measuring wires for micrometers with measuring faces ø 6.35, ø 6.5 or ø 8 mm

ø 6.35 mm ø 6.5 mm ø 8 mm Wire Metric, W hitworth, UN/UNC/UNF,
Item No. Price Item No. Price Item No. Price diameter
DKK DKK DKK dD/mm pitch threads threads

833.442 779.161 836.689 in mm per inch per inch
833.443 781.651 836.690
833.444 779.162 836.691 0.17 0.25; 0.3 – –
833.445 779.163 835.844 0.195 80
833.446 779.164 834.499 0.22 – – 72
833.447 779.165 834.498 0.25 64
833.448 781.652 837.848 0.29 0.35 – 56
833.449 779.166 833.872 0.335 48; 44
833.450 779.167 834.585 0.390 0.4 – 40
833.451 779.168 834.480 0.455 36
833.452 779.169 834.586 0.53 0.45; 0.5 – 32; 28
833.453 779.170 834.290 0.62 24
833.454 779.171 834.502 0.725 0.6 40 20
833.455 779.172 834.291 0.895 18; 16
833.456 779.173 833.871 1.10 – – 14; 13
833.457 779.174 834.292 1.35 12; 11
833.458 779.175 834.416 1.65 0.7 - 0.8 – 10; 9
833.459 779.176 834.483 2.05 8; 7
837.501 837.642 834.509 2.55 – 32; 28 6
3.20 5; 4.5
834.580 779.160 834.581 4.00 1 26; 24 4

1.25 22; 20; 19

1.5 18; 16

1.75 14

2 12; 11

2.5 10; 9

3.0; 3.5 8; 7

4.0; 4.5 6

5.0; 5.5 5; 4.5

6.0 4; 3.5

Set with wire diameters 0.17 to 3.20 mm
