www.mtsranders.dk                                                                  MICROSCOPES

  Stand microscopes 20x ... 100x with LED illumination

  These stand microscopes are available in four ver­sions. All four are compact and lightweight,
but are especially characterized by their large field of view. Delivered in a case, including LED
ring light, matching standard scale and objective. The microscopes come with a Huygens eyepiece
(magnification 10x) and with a detachable soft rubber eye adapter. All-purpose use with high
precision.

  A scale graduation (with a 10 mm scale range) has been engraved on the focusing ring which
allows height measurements at a resolution of 0.1 mm.
	 Focusing with helicoid ring.
	 Eyepiece: 10x.
	 Illumination: 3 LEDs.
	 Dimensions: ø 41.5 x 122 mm.
	 Weight (without batteries): 285 g.
	 Power supply: 4 batteries type V394.

                                                                                                                                                               910.422

Item No.  Magnification 	               Price
           microscope                   DKK
                                                         910.404                                 910.404
Standard scales:    20x                                 910.414                                  910.418
910.414 	           40x
910.415 	           60x
910.416 	          100x
910.417

910.422 Individual eyepiece 10x

Objectives:
910.418 Individual objective 2x
910.419 Individual objective 4x
910.420 Individual objective 6x
910.421 Individual objective 10x

Item No.  	 Magnification	 Objective    Field of view 	 Working 	     Measuring 	  Graduation 	  Price
                                                                      range/mm         mm        DKK
910.404                                 ø/mm    distance/mm
910.405                                                                   0	           0.1
910.406   	 20x	     2x                 	 3.3   	 17               	      1.6 	        0.05
910.407   	 40x	     4x                 	 2.0   	 11.7             	      1.0 	        0.02
          	 60x	     6x                 	 1.1   	 11.7             	      0.8 	        0.01
Options:  	 100x	  10x                  	 0.84  	 11.6
420.248
910.408   Battery type V394 (4 needed)                                                                                                                                  C13.329.MTS.20250410
          LED ring light
