P. 516
DEMEET 3D CNC MEASURING MACHINES Schut for Precision
Field of view qualifier Qualification spheres
Glass reference standard with a pattern Ball: ø 8 or ø 25 mm, made of ceramics.
consisting of wide variety of very accurate Delivery with a manufacturer measuring
optical characteristics, produced with a coat‑
ing (chrome). Very suitable for use with optical report.
instruments as geometric accuracy standard or
as a test and training object. 707.008
Accuracy: ± 0.002 mm. 3.9 50
Delivery including drawing with size 9.5
indication. 5.4 8
11.4
6
5.9
16.3
100
7.5
15.5
ø8 ø8 ø12.5
ø12.5
707.013 65 707.024
Item No. Description Price EUR Item No. Description Price EUR
635.222 Field of view qualifier 155.00 Qualification sphere ø 8 mm: 445.00
707.0251 For DeMeet-220 398.00
Worktable DeMeet‑220 707.0262 For DeMeet-4xx/705
390.00
The DeMeet‑220 must be placed on a stable Qualification sphere ø 25 mm: 366.00
worktable for accurate measurements. Placing 707.0131 For DeMeet-220 277.00
can be done on a strong work table or on a granite 707.0242 For DeMeet-4xx/705
worktable like below. 707.0082 Ball only; M6 external thread
1 Thread M4.
2 Thread M6.
Training object
Delivery ex Groningen, Netherlands
Item No. Description Price EUR
402.004 Granite surface plate 506.00
630 x 630 x 80 mm, DIN 876/1
131.032 Support DeMeet‑220 399.00 Item No. Description Price EUR C23.305.EN.20240626
(working height 750 - 800 mm) 635.200 Touch probe training object 210.00
© 2024, Schut Geometrische Meettechniek bv 516 Measuring instruments and systems 2023/2024
