Page 330 - Schut Catalog
P. 330
CENTER SQUARES / CALIPER COMPASSES www.promet.se
Center squares
Center squares with mm graduation on the blade, to mark the center on round discs or axes.
Stainless steel construction, no-glare chrome
finished.
Graduation placed by means of a laser.
Item No. Length/mm Max. ø Price
l1 l2 mm SEK
907.893
907.893 100 70 90 435.60 l2
907.894 150 130 190 492.00
907.895 200 150 220 564.00 l1
907.896 250 160 230 936.00
907.897 300 180 280 1,164.00 Fixed jaw and beam made out of one piece.
909.972 400 250 380 1,548.00 Hardened, ground and lapped measuring faces.
909.973 500 330 530 2,220.00
Caliper compasses
For scribing of diameters of 0 - 600 mm.
Vernier: 0.1 mm.
Stainless steel construction, matt chrome-
plated.
909.425
Item No. For scri- Meas. Jaw Price
bing up range length SEK
to ø/mm mm mm
909.424 300 150 40 624.00 C15.205.Promet.20240517
909.425 400 200 40 744.00
909.426 500 250 40 900.00
909.427 600 300 40 1,020.00
© 2024, Schut Geometrische Meettechniek bv 330 Promet Precision 2023/2024-D
