www.promet.se MICROSCOPES
Stand microscopes 20x ... 100x with LED illumination
These stand microscopes are available in four versions. All four are compact and lightweight,
but are especially characterized by their large field of view. Delivered in a case, including LED
ring light, matching standard scale and objective. The microscopes come with a Huygens eyepiece
(magnification 10x) and with a detachable soft rubber eye adapter. All-purpose use with high
precision.
A scale graduation (with a 10 mm scale range) has been engraved on the focusing ring which
allows height measurements at a resolution of 0.1 mm.
Focusing with helicoid ring.
Eyepiece: 10x.
Illumination: 3 LEDs.
Dimensions: ø 41.5 x 122 mm.
Weight (without batteries): 285 g.
Power supply: 4 batteries type V394.
910.422
Item No. Magnification Price
microscope SEK
910.404 910.404
Standard scales: 20x 163.20 910.414 910.418
910.414 40x 163.20
910.415 60x 163.20
910.416 100x 163.20
910.417 432.00
910.422 Individual eyepiece 10x 900.00
936.00
Objectives: 960.00
910.418 Individual objective 2x 984.00
910.419 Individual objective 4x
910.420 Individual objective 6x
910.421 Individual objective 10x
Item No. Magnification Objective Field of view Working Measuring Graduation Price
range/mm mm SEK
910.404 ø/mm distance/mm
910.405 0 0.1 1,464.00
910.406 20x 2x 3.3 17 1.6 0.05 1,524.00
910.407 40x 4x 2.0 11.7 1.0 0.02 1,632.00
60x 6x 1.1 11.7 0.8 0.01 1,716.00
Options: 100x 10x 0.84 11.6
420.248 18.00
910.408 Spare battery type V394 (4 needed) 552.00 C13.329.Promet.20240517
LED ring light
