www.promet.se MAGNIFIERS

Peak ABC magnifier 3-18x Magnifier on magnetic stand

The ABC magnifier consists of three lenses.  Magnification: 2x (ø 90 mm).
Combining the three lenses, seven different  Total length: 280 mm.
magnifications are possible.  Magnetic force: 600 N.
 Magnification: 3x, 6x, 9x, 12x, 14x, 16x and 18x.
 Magnification and diameter of the lenses:

lens A: 12x, ø 14 mm,
lens B: 3x, ø 28 mm,
lens C: 6x, ø 20 mm.
 Dimensions: 60 x 39 x 24 mm.
 Weight: 76 g.

Item No. Description Price SEK Item No. Description Price SEK
909.609 Magnifier on 322.80
905.196 ABC magnifier 3-18x 3,504.00
magnetic stand

Peak magnifying glass 2.5 - 5x Peak flexible stand magnifier

This model of the classic magnifying glass This magnifier has a flexible arm which can be
has a lens-in-lens construction. In the big ø 75 mm adjusted freely from a solid and stabilized stand.
lens a smaller ø 20 mm lens has been integrated The lens can be put in many positions for the
which offers extra strong magnification. The big most ergonomic use thus leaving both hands of
lens has a 2.5x magnification, the small lens 5x. the user free.
 Dimensions: ø 80 x 170 mm.  Dimensions:
 Weight: 111 g.
145 x 120 x 485 mm
(maximum height).
 Weight: 1.5 kg.

905.279

Item No. Description Price SEK Item No. Magnification Lens Price C13.212.Promet.20240517
ø/mm SEK

905.214 Magnifying glass 2.5 - 5x 355.20 905.279 1.7x 115 1,044.00
905.428 2.2x 90 876.00
