www.prenar.ee SURFACE PLATES

Cast iron surface plates

Extra heavy, cast iron surface plates. 403.212
 Three models:
Delivery ex Groningen, Netherlands
– milled (smoothened), accuracy according
DIN 876/3,
– hand scraped, accuracy according
DIN 876/1,
– fine scraped, accuracy according
DIN 876/0.
 The side faces of all plates are milled and
varnished.
 Surface plate stand optionally available
(see “surface plate accessories” elsewhere in
this catalog).

Dimensions Weight Accuracy according Accuracy according Accuracy according
l x w kg DIN 876/3 DIN 876/1 DIN 876/0
mm (approx.)
Item No. Price EUR Item No. Price EUR Item No. Price EUR
200 x 200 7 403.236 403.208 403.185
250 x 250 12 403.237 403.209 403.186
300 x 300 15 403.238 403.210 403.187
400 x 250 25 403.239 403.211 403.188
400 x 400 35 403.240 403.212 403.189
500 x 500 50 403.241 403.213 403.190
600 x 400 45 403.242 403.214 403.191
630 x 630 90 403.243 403.215 403.192
800 x 500 95 403.249 403.221 403.193
1000 x 600 140 403.245 403.217 403.194
1000 x 1000 270 403.246 403.218 403.195
1200 x 800 300 403.250 403.222 403.196
2000 x 1000 1000 403.248 403.220

Fine scraped plate (DIN 876/1) with lapp and inspection surface

Cast iron duplex plate with one flat inspection surface
and one squared lapp surface, both finely scraped
according to DIN 876/1. With the optional wooden box the
surface plate can be used on both sides, because the top
and bottom side of the case can be separated.
 Flatness: 14 µm.
 Dimensions l x w x h:

360 x 260 x 65 mm.
 Weight: approx. 24 kg.

Item No. Description Price EUR C06.218.Prenar.20240422
403.150 Duplex plate
403.151 Wooden case (double sided use)

175
