Page 40 - Schut Catalog
P. 40
CALIPERS Schut for Precision
Mitutoyo Absolute Digimatic Coolant Proof calipers IP67
Series digital calipers with the unique Absolute measuring system to prevent inaccuracy due to an
incorrect zero position. These IP67 protected calipers are especially suitable for use in production
environments; they even last temporary immersion. The one-time setting of origin remains as the
absolute zero position until the battery has to be changed.
Measuring range: 0 - 300 mm. Flat depth rod (except 500.709: round depth
Resolution: 0.01 mm. rod ø 1.9 mm).
With or without Digimatic data output.
Digit height: 9 mm. Protection: IP67.
Automatic switch-off. Battery life: approx. 18 000 hours.
Reset. Delivery in a plastic case with a manufacturer
Max. measuring speed: unlimited.
Locking screw. measuring report.
Power supply: 1 battery type V357.
Also available with thumb wheel.
500.706
Item No. Measuring Accuracy Jaw length Price
range/mm mm mm EUR
Without Digimatic data output: 40 202.00
500.706 0 - 150 0.02 40 203.00
500.709 1 0 - 150 0.02 50 279.00
500.707 0 - 200 0.02 64 398.00
500.708 0 - 300 0.03
With Digimatic data output: 256.00
500.716 0 - 150 0.02 40 507.00
500.727 2 0 - 150 0.02 40 325.00
500.717 0 - 200 0.02 50 566.00
500.728 2 0 - 200 0.02 50 427.00
500.718 0 - 300 0.03 64
1 With round depth rod ø 1.9 mm. Options
2 Provided with tungsten carbide measuring faces.
3 With data switch. Item No. Description Price EUR
4 Connector + transmitter are needed.
836.535 Spare battery type V357 0.90
105.624 3 Digimatic signal cable, 1 m 100.00 C02.305.EN.20240625
105.625 3 Digimatic signal cable, 2 m 107.00
106.381 3 USB Input Tool Direct cable 2 m 141.00
102.310 3,4 U-WAVE fit connector IP67 110.00
264.620 4 U-WAVE fit transmitter IP67 187.00
264.621 4 U-WAVE fit transmitter 187.00
264.624 4 U-WAVE Bluetooth transmitter IP 67 187.00
264.625 4 U-WAVE Bluetooth transmitter 187.00
© 2024, Schut Geometrische Meettechniek bv 40 Measuring instruments and systems 2023/2024
