Schut Geometrical Metrology CALIPERS
TESA TWIN-Cal absolute digital calipers IP67
New generation IP67 calipers, TESA TWIN-Cal, with an absolute measuring system and a “soft
touch” grip. These calipers have a unique connectivity concept TESA LINK. All TWIN-Cal calipers
are equipped with a data output. Connect the TESA Link Connector to the TWIN-Cal for “plug and
play” (wireless) data transfer in combination with the free to download TESA Data-Viewer software.
Measuring range: 0 - 300 mm. Locking screw.
Resolution: 0.01 mm. Round (ø 1.5 mm) or flat depth rod.
Repeatability: 0.01 mm. Protection: IP67 (also in combination with
mm/inch conversion.
Digit height: 11 mm. data output cable).
Automatic switch-off. ISO 13385-1.
Reset. Standard supplied with data output (USB,
Max. measuring speed: approx. 2.5 m/s.
Thumb wheel (except 783.290/291); also Digimatic or wireless).
Delivery in a plastic case with a manufacturer
optionally available.
measuring report.
Power supply: 1 battery type CR2032.
783.291
6
Dimensions 1.7 Also available as a set.
flat depth rod
C02.306.EN.20250106
Item No. Measuring Jaw length Depth Price
range/mm mm rod EUR
783.290 0 - 150 40 flat 193.00 C/ON ABS/C USB 2.0
783.291 0 - 150 40 round 193.00
783.292 0 - 150 40 round 194.00 TESA Link Connector USB
783.293 0 - 200 50 263.00
783.294 0 - 300 64 flat 337.00
flat
Options: 0.50 C/ON ABS/C
495.157 Battery type CR2032 37.00
779.362 1 Depth measuring base 75 x 6 mm 11.50 TESA Link Connector Digimatic
783.300 1 Thumb wheel 128.00
783.301 2 TESA Link Connector USB 262.00 C/ON ABS/C
783.302 2 TESA Link Connector Digimatic 52.00
783.555 2 TESA Link Connector Bluetooth TESA Link Connector Bluetooth
1 Only suitable for the calipers with measuring range 0 - 150 mm.
2 The TESA Link Connector will replace the battery cover.
