www.sometcz.com DIAL INDICATORS

Precision dial indicator

Highly accurate dial indicator for measurements from a fixed reference point. Very suitable for
internal measuring instruments and dial indicator stands for example.
 Measuring range: 0.1 mm.
 Graduation: 0.001 mm.
 Measuring force: < 2 N.
 Clamping stem: ø 8 mm.
 Travel: 3 mm.
 Adjustable tolerance markers.
 Fine adjustment.
 Delivery in a plastic case with a manufacturer

measuring report.

Item No. Measuring Dial Price
range/mm ø/mm CZK

907.939 0.1 63.5

Precision dial indicators

 Measuring range: 0.06 mm.
 Graduation: 0.0005 mm or 0.001 mm.
 Measuring force: approx. 1 N.
 Clamping stem: ø 28 mm.
 Shockproof.
 Fine adjustment.
 Delivery with an inspection report.

For dial indicator stands see dial indicator
stands elsewhere in this catalog.

Item No. Measuring Resolution Scale Price
range/mm mm numbering CZK
15 - 0 - 15 C05.339.Somet.20240422
906.332 0.03 0.0005 30 - 0 - 30 906.333
906.333 0.06 0.001

139
