www.sometcz.com                                   SETTING INSTRUMENTS

  Setting instrument for internal measuring instruments

  This instrument offers you the best way to
accurately set the zero position of your internal
measuring instruments with dial indicator.
Gauge blocks are used to set the exact reference
value. The special mounting hole assures that
the centering device of the micrometer also
functions when in use on this instrument,
making the checking just as easy as measuring.
	 Adjustment range: 18 - 400 mm.
	 The setting instrument consists of a stand with

  double guidance and a flat measuring jaw.
	 Excl. gauge blocks.
	 Delivery in a wooden box.

Item No. Adjustment range/mm Price CZK

907.877 	  18	-	400

  Setting gauges for inside micrometers

  Used for setting of inside micrometers.
	 Measuring range: 50 - 275 mm.
	 Delivery in a wooden case.

                                                  910.005

                     Item No. Length 	 Accuracy 	 Parallelism 	        Price
                                             mm mm              mm     CZK

                     910.005 	                50  	 ± 0.003  	  0.003         C04.226.Somet.20240422
                     910.006 	                75  	 ± 0.004  	  0.004
                     910.007 	               100  	 ± 0.005  	  0.005
                     910.008 	               150  	 ± 0.005  	  0.005
                     910.009 	               200  	 ± 0.005  	  0.005
                     910.010 	               250  	 ± 0.005  	  0.005
                     910.011 	               275  	 ± 0.005  	  0.005
