Page 49 - Schut Catalog

www.promet.se DEPTH GAUGES

Depth caliper for keyway depths Depth calipers for keyway depths

 Measuring range: keyway depths 0 - 25 mm.  Measuring range: keyway depths 0 - 60 mm.
 Application range: cylinders ø 5 - 200 mm.  Application range: cylinders ø 5 - 200 mm.
 Resolution: 0.01 mm.  Vernier: 0.05 mm.
 mm/inch conversion.  Stainless steel construction.
 On/off switch.
 Reset.
 Large LCD display.
 Locking screw.
 Measuring pin: ø 2 mm.
 Power supply: 1 battery type V357.

Item No. Application range/mm Price SEK Item No. Application range/mm Price SEK

910.258 ø 5 - 200 2,100.00 907.192 ø 5 - 80 1,356.00
907.193 ø 6 - 120 1,644.00
Option: 10.80 907.194 ø 7 - 160 1,908.00
836.535 Spare battery type V357 907.195 ø 8 - 200 2,208.00

Digital depth gauge Käfer depth dial indicators

 Measuring range: 0 - 80 mm.  Measuring range: 0 - 30 mm.
 Resolution: 0.05 mm.  Graduation: 0.01 mm.
 mm/inch conversion.  Measuring pin shaft: ø 2 mm.
 On/off switch.  Measuring depth with pin
 Detachable measuring pin
852.385: 200 mm.
ø 4.3 mm, length 50 mm.  Excl. measuring pin and
 Power supply: 1 battery
measuring base.
type CR2032.  Accuracy according

DIN 878 (852.383) or factory
standard (852.384).

Item No. Measuring range/mm Price SEK

852.383 0 - 10 1,872.00
852.384 0 - 30 3,288.00

Item No. Measuring range/mm Price SEK Options:
852.385 Measuring pin ø 2 mm, 129.60
906.428 0 - 80 379.20 C02.232.Promet.20240517
340 mm
Option: 907.153 Meas. base 63 x 17 mm 237.60
495.157 Spare battery type CR2032 6.00 907.165 Meas. base 101.5 x 17 mm* 249.60

* Larger sizes available on request.

© 2024, Schut Geometrische Meettechniek bv 49 Promet Precision 2023/2024-D
