P. 305
www.promet.se STEREO MICROSCOPES
Stereo microscopes with stepless zoom SSM‑E
Stereo zoom microscopes with a sharp erect image and a large field of view. The special microscope
head is equipped with stepless zoom; in combination with the standard 10x eyepieces (optionally 20x)
you can smoothly zoom in from 10x to 40x magnification. The magnification can be adjusted to your
application even more with an optional auxiliary lens (0.5x, 0.75x, 1.5x or 2x). For all accessories,
please refer to the pages “SSM stereo microscope accessories”.
Stand with round (flattened) column and anti Delivery incl. dust cover, soft rubber eye
drop facility. adapters and black/white stage plate.
Microscope head: 360° rotatable. Power supply: 230 Vac (50 Hz).
Viewing angle: 45°.
Interpupillary distance: adjustable (55 - 75 mm). Item No. Type Magnification Price SEK
Both eyepieces with diopter adjustment: ± 5 dpt.
Working distance (without aux. lens): 85 mm. 909.010 SSM‑EC2 10 - 40x 5,364.00
Equipped with LED incident light and LED 908.998 SSM‑3EC2 10 - 40x 6,072.00
backlight, and the luminous intensity is See for accessories the pages “SSM stereo
adjustable. microscope accessories”.
Stage plate: opal glass.
909.010 908.998
Type SSM‑EC2 SSM‑3EC2 908.998
Eyepiece M 10x 10x Camera connection
Model 3EC2 is equipped with camera
Objective M 1-4x 1-4x
connection. See the accessories page for the
Total range * M 5-160x 5-160x total magnification range with camera.
Illumination yes yes
Max. object height mm 110 110
Travel of rack mm 60 60
Stage plate ø/mm 95 95
Dimensions lxwxh/mm 330x235x360 330x235x395
Weight kg 4.8 5.4 C13.307.Promet.20240517
* The magnification range of the microscope in combination
with the 10x eyepieces, the optional 20x eyepieces and the
optional auxiliary lenses 0.5‑2x.
© 2024, Schut Geometrische Meettechniek bv 305 Promet Precision 2023/2024-D
