P. 276
GAUGES www.promet.se
Flat plug gauges 907.876
Measuring range: 1 - 60 mm. Item No. Measuring range/mm Price SEK
Graduation: 0.1 mm.
Stainless steel, matt chrome- 907.876 1 - 15 250.80
909.516 15 - 30 291.60
plated finish. 909.517 30 - 45 368.40
Graduation on both sides. 909.534 45 - 60 480.00
Ground measuring faces.
Laser engraving. 909.490
Conical plug gauges Item No. Measuring range/mm Price SEK
Measuring range: ø 1 - 45 mm. 909.490 ø 1 - 6 624.00
Graduation: 0.1 mm. 909.491 ø 4 - 15 900.00
Hardened, ground and chrome 909.492 ø 15 - 30 1,044.00
909.493 ø 30 - 45 1,440.00
finished.
With anodized handle. Nozzle gauges with vernier
Nozzle gauges Nozzle gauges with a hardened and ground
tapered needle.
Set of pins in holder serving as a gauge to Measuring range: ø 0 - 5 mm.
determine jet nozzle sizes. Vernier: 0.01 mm.
856.107
Item No. Number Sizes Price
of pins mm SEK
856.107 20 ø 0.45 - 1.50 69.60 Item No. Measuring range/mm Price SEK C12.213.Promet.20240517
856.108 16 ø 1.50 - 3.00 69.60
856.124 16 ø 3.00 - 4.50 165.60 856.110 ø 0 - 5 684.00
856.125 16 ø 4.50 - 6.00 165.60
