www.promet.se SPIRIT LEVELS
Circular spirit levels
Item No. Diameter Heigth Sensitivity * Price
mm mm mm/m SEK
857.318
Plexiglass model with yellow and green base: 857.323
857.315 12 7 approx. 22 63.60
857.316 15 8 approx. 22 73.20 857.336
857.317 18 9 approx. 22 86.40
857.318 30 10 approx. 22 122.40
Black synthetic model with frame and screw holes ø 2.5 mm and 857.320
yellow and green base: 857.331
857.320 26 / 17 7 + 3 approx. 19 145.20 857.337
857.321 30 / 20 7.5 + 3.5 approx. 19 187.20
Chrome casing and white base:
857.323 15 10 approx. 8 344.40
857.324 18 10 approx. 8 397.20
Chrome casing with frame and screw holes ø 2.5 mm
(857.325: ø 1.5 mm; 857.330/331: ø 3.5 mm) and white base:
857.325 20 / 13.5 7 + 2 approx. 8 423.60
857.326 25 / 17 7.5 + 2.5 approx. 8 448.80
857.327 30 / 17 6.5 + 3.5 approx. 8 476.40
857.328 35 / 20 7.5 + 3.5 approx. 6 684.00
857.329 40 / 25 8 + 4 approx. 6 876.00
857.330 50 / 34 9.5 + 5.5 approx. 3 1,272.00
857.331 60 / 39 10 + 7 approx. 3 1,404.00
857.332 25 / 17 7.5 + 2.5 approx. 2 516.00
White, synthetic casing with frame and screw holes ø 3 mm,
additional scale circles and white base:
857.336 60 / 45 4 + 6 Reading 864.00
0° - 2° - 5°
Black, synthetic casing with frame and screw holes ø 5 mm,
additional scale circles and white base:
857.337 100 / 75 5 + 10 Reading 960.00
0° - 3° - 6°
* Sensitivity means: the angle at which the air bubble is moved to the next scale
mark or edge of the vial.
Hose water level
Measuring range: 15 cm.
Graduation: 1 mm.
Scale numbering: 0.5 - 15.5 cm.
Hose length: 20 m (reducible).
Hose cross-section: 9.5 mm.
Item No. Description Price SEK C08.221.Promet.20240517
906.819 Hose water level 181.20
