P. 224
PROTRACTORS / CLINOMETERS www.promet.se
Universal digital bevel protractors
Digital bevel protractors for measuring both inside and outside angles. Equipped with a locking
knob for measuring a specific angle.
Measuring range: ± 360°. Locking screw.
Resolution: 0.1°. Power supply: 1 battery type CR2032.
Accuracy: ± 0.3°.
On/off switch.
Automatic switch-off.
Zero setting at any position.
Graduation rulers: 1 mm and 1/32 inch.
Cross-section rulers: 35 x 2.5 mm.
With fixing holes.
Item No. Ruler length/mm Price SEK
909.505 200 363.60 909.505
909.506 300 472.80
45°
Option:
495.157 Spare battery type CR2032 6.00 For marking
angles on
Magnetic clinometer with center point finder cylindrical
and spherical
Accurate clinometer with an extremely sensitive, balanced needle. The surfaces.
magnetic base with 90° V‑groove is precision milled. The center point
finder can be used as a center punch.
Very suitable for angular measurements, surface alignment, and the
determination of center points and highest/lowest points of cylindrical and
spherical surfaces. Therefore ideal as a universal aid to the installation of
larger constructions.
Measuring range: 360°.
Graduation: 1°.
Scale numbering: 0 - 360.
Aperture V‑groove (horizontal): 82 mm
(for shafts up to ø 115 mm).
Dimensions h x w x d: 130 x 130 x 27 mm.
Item No. Scale numbering Price SEK
3,984.00
856.702 0 - 360
Option: 856.702 C08.303.Promet.20240517
856.712 Center pin
ø 12 x 125 mm
© 2024, Schut Geometrische Meettechniek bv 224 Promet Precision 2023/2024-D
