www.mtsranders.dk                                                  DIAL INDICATORS

Absolute horizontal digital dial indicators

	 Measuring range: 0 - 30 mm.                            	 Reversible measuring direction.
	 Resolution: 0.001 mm.                                  	 Protection: IP54.
	 mm/inch conversion.                                    	 Delivery with a manufacturer measuring report.
	 Digimatic data output.                                 	 Power supply:
	 On/off switch.
	 Reset/preset.                                            910.085: 1 battery type CR1632,
	 Ceramic stylus tip.                                      910.086: 1 battery type CR2032.
	 With dovetail joint (incl. lug) and clamping            USB interface and wireless USB receiver and

  stem ø 8 mm.                                                     transmitter available on request.
	 Measuring force: ≤ 2 N.

                                                                   910.085

                                Item No. Measuring 	 Resolution 	 Accuracy 	                       Price
                                                     range/mm  mm           mm                     DKK

                                910.085 	 0	-	12.7 	 0.001 	 ± 0.005
                                910.086 	 0	-	30 	 0.001 	 ± 0.006

                                Options:
                                497.955 Battery type CR1632
                                495.157 Battery type CR2032

Digital dial indicator with calculation function

  Robust digital dial indicator with built-in calculation function for easy determination of diameters
by means of measuring a curved surface. Suitable for measuring both inside and outside diameters
and multifunctional dial indicator applications. Delivery with measuring bases of 10, 20, 30, 60 and
100 mm.

	 Measuring range: 0 - 13 mm.                            	 Hold function.
	 Resolution: 0.005 mm.                                  	 Clamping stem: ø 8 mm.
	 mm/inch conversion.                                    	 Aluminum construction.
	 On/off switch.                                         	 Delivery in a plastic case.
	 Reset.                                                 	 Power supply: 1 battery type CR2032.

Item No. Measuring 	 Accuracy 	 Price
range/mm                        mm DKK

907.884 	 0	-	13 	 ± 0.005 *

Option:
495.157 Battery type CR2032

*	Accuracy of the indicator without the use of                                                               C05.329.MTS.20250410
 measuring bases. The accuracy with measuring bases
 depends on the radius and form deviation of the
 workpiece.
