P. 435
SGM – Schut Geometrische Messtechnik VIDEOMIKROSKOPE
Dino-Lite USB-Video-Messmikroskope (Fortsetzung)
Bestell-Nr. 774.081 774.088 774.210 774.106 774.024 1 774.250 1 774.277 1 774.278 1 774.280 1
Typ AM4113T AM4113ZT AM4115TL AM4013MZTL AM4115ZTL AM4115TF AF4115ZT AF4915ZT AF4915ZTL
Preis EUR 349,00
Vergrößerung (stufenlos) 10-70x 429,00 539,00 619,00 629,00 639,00 639,00 929,00 929,00
10-70x 10-140x 10-90x 10-140x 10-70x 20-220x 20-220x 10-140x
Vergrößerung (fest) 200x 200x – – – – – – –
Auflösung px 1,3 M 1,3 M 1,3 M 1,3 M 1,3 M 1,3 M 1,3 M 1,3 M 1,3 M
FLC 2 – – – – – – ✓ ✓ ✓
EDOF/EDR 3 – – – – – – – ✓ ✓
AMR 4 – – – – – – – ✓ ✓
Gesichtsfeld (mm)
min. Vergrößerung 19,8x14,9 19,8x14,9 39,0x31,2 19,8x14,9 39,0x31,2 39,0x31,2 19,5x15,6 19,5x15,6 39,0x31,2
max. Vergrößerung 1,7x1,2 1,7x1,2 2,8x2,2 4,4x3,3 2,8x2,2 5,6x4,5 1,8x1,4 1,8x1,4 2,8x2,2
Polarisator – ✓ – ✓ ✓ – ✓ ✓ ✓
Großer Arbeitsabstand – – ✓ ✓ ✓ ✓xtra – – ✓
mm -2..48 -2..48 30..234 46..151 30..234 115..480 4..60 4..60 30..234
Abnehmbare Frontseite – – ✓ – ✓ ✓ ✓ ✓ ✓
Aluminium Gehäuse – – – ✓ – – – – –
Abnehmbare Kabel für – – – – – – ✓ ✓ ✓
WiFi Module
USB-Interface 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
Bestell-Nr. 774.330 774.314 6 774.216 1 774.251 1 774.246 1 774.228 1 774.229 1 774.252 1 774.253 1
Typ AM7515MZT2P AM4917MZT AM7115MZTL AM73115MTF AM73115MZT AM7915MZT AM7915MZTL AM73915MZT AM73915MZTL
Preis EUR 1.099,00 1.169,00 929,00 1.099,00 1.099,00 1.169,00 1.169,00 1.399,00 1.399,00
Vergrößerung (stufenlos) 1 30-220x 20-220x 10-140x 10-70x 10-220x 10-220x 10-140x 10-220x 10-140x
Laser Pointer ✓ – – – – – – – –
Auflösung px 5 M 1,3 M 5 M 5 M 5 M 5 M 5 M 5 M 5 M
FLC 2 ✓ ✓ eFLC ✓ ✓ ✓ ✓ ✓ ✓ ✓
EDOF/EDR 3 – ✓ – – – ✓ ✓ ✓ ✓
AMR 4 ✓ ✓ – – – ✓ ✓ ✓ ✓
Gesichtsfeld (mm)
min. Vergrößerung 3,0x2,2 19,5x14,7 39,0x31,2 39,0x31,2 37,8x28,3 37,8x28,3 39,0x31,2 37,8x28,3 39,0x31,2
max. Vergrößerung 1,8x1,3 1,8x1,3 2,8x2,2 5,6x4,5 1,8x1,3 1,8x1,3 2,8x2,2 1,8x1,3 2,8x2,2
Polarisator ✓ ✓ ✓ – ✓ ✓ ✓ ✓ ✓
Großer Arbeitsabstand – – ✓ ✓xtra – – ✓ – ✓
mm 4,5..11,9 4..60 30..234 115..480 12..136 12..136 30..234 12..136 30..234
Abnehmbare Frontseite ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
Aluminium Gehäuse ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
USB-Interface 2.0 2.0 5 2.0 3.0 3.0 2.0 2.0 3.0 3.0
1 Neue “Edge” Generation mit verbesserten Optiken und auswechselbaren Frontkappen. C13.320.DE.20240626
2 FLC: Flexible LED Control. eFLC: 2 separate Intensitäten möglich.
3 EDOF: Höhere Tiefenschärfe / EDR: Höherer Kontrast.
4 AMR: Automatische Vergrößerungsablesung.
5 Abnehmbares Micro-USB-Kabel (mitgeliefert).
6 Neue “Edge plus” Generation mit indikativer Tiefenmessung.
© 2024, Schut Geometrische Meettechniek bv 435 Messgeräte und -systeme 2023/2024
